SpringBoot整合Swagger

2022-5-8

本文最后更新于2022.10.11-05:35，某些文章具有时效性，若有错误或已失效，请在下方留言或联系涛哥。

作用

是一个动态生成接口文档的一个框架，用于和前端或测试岗位的同事进行对接。

实现案例

1，在pom.xml里导入依赖配置

<!--导入swagger-->
        <dependency>
            <groupId>io.springfox</groupId>
            <artifactId>springfox-swagger2</artifactId>
            <version>2.9.2</version>
        </dependency>
        <!--swagger用来生成前端页面-->
        <dependency>
            <groupId>io.springfox</groupId>
            <artifactId>springfox-swagger-ui</artifactId>
            <version>2.9.2</version>
        </dependency>

2，新建一个config文件夹并新建以下文件

SwaggerConfig.java

package com.xxgc.helloworld.config;

import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;
import org.w3c.dom.DocumentType;
import springfox.documentation.builders.ApiInfoBuilder;
import springfox.documentation.builders.PathSelectors;
import springfox.documentation.builders.RequestHandlerSelectors;
import springfox.documentation.service.ApiInfo;
import springfox.documentation.spi.DocumentationType;
import springfox.documentation.spring.web.plugins.Docket;
import springfox.documentation.swagger2.annotations.EnableSwagger2;

@Configuration
@EnableSwagger2
public class SwaggerConfig {
    @Bean
    public Docket createRestApi(){
        return new Docket(DocumentationType.SWAGGER_2)
                .apiInfo(apiInfo())
                //是否开启前端ui显示 生产环境调为false
                .enable(true)
                .select()
                //扫描有哪些接口（controller）要生成文档
                .apis(RequestHandlerSelectors.basePackage("com.xxgc.helloworld.controller"))
                //接口中所有路径都扫描
                .paths(PathSelectors.any())
                .build();
    }

    private ApiInfo apiInfo(){
        return new ApiInfoBuilder()
                //api文档标题
                .title("HelloWorld工程")
                //文档描述
                .description("工程文档描述")
                //服务条款url
                .termsOfServiceUrl("https://www.baidu.com")
                //版本号
                .version("1.0.0")
                .build();
    }
}

InterceptorConfig.java

package com.xxgc.helloworld.config;

import com.xxgc.helloworld.interceptor.JWTInterceptors;
import org.springframework.context.annotation.Configuration;
import org.springframework.web.servlet.config.annotation.InterceptorRegistry;
import org.springframework.web.servlet.config.annotation.WebMvcConfigurer;

import java.util.ArrayList;

/**
 * @program: helloword
 * @description: 拦截器配置
 * @author: liutao
 * @create: 2022-03-07 16:11
 **/
@Configuration
public class InterceptorConfig implements WebMvcConfigurer {

    //配置拦截器规则
    public void addInterceptors(InterceptorRegistry registry){
        //swagger相关
        ArrayList<String> swagger = new ArrayList<>();
        swagger.add("/*.html");
        swagger.add("/swagger-resources/**");
        swagger.add("/webjars/**");
        swagger.add("/v2/**");
        swagger.add("/swagger-ui.html/**");
    }
}

3，使用

controller.java

package com.xxgc.helloworld.controller;

import com.xxgc.helloworld.po.Info;
import io.swagger.annotations.Api;
import io.swagger.annotations.ApiOperation;
import io.swagger.annotations.ApiParam;
import org.springframework.beans.factory.annotation.Value;
import org.springframework.context.annotation.PropertySource;
import org.springframework.stereotype.Controller;
import org.springframework.web.bind.annotation.GetMapping;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.ResponseBody;

@Controller
@PropertySource(value = "classpath:system.properties")
@RequestMapping("/info")
@Api(value="hello接口",tags ="用于返回helloworld",description = "测试helloworld")
public class HelloController {
    @Value("${system.name}")
    private String system;

    @ApiOperation(value = "获取helloworld",notes = "获取helloworld")
    @GetMapping("/hello")
    @ResponseBody
    public Info hello(){
        return new Info(200,system+"hello world");
    }

    @ApiOperation(value = "给什么返回什么",notes = "你给什么返回什么")
    @GetMapping("/getMsg")
    @ResponseBody
    public Info getMsg(@ApiParam(name="msg",value="信息",required = true) String msg){
        return new Info(-201,msg);
    }
}

效果图
