SpringBoot+WebSocket实现即时通讯（J2EE方式）

2022-8-19

本文最后更新于2023.04.22-17:59，某些文章具有时效性，若有错误或已失效，请在下方留言或联系涛哥。

什么是websocket？

WebSocket是一种在单个TCP连接上进行全双工通信的协议。WebSocket通信协议于2011年被IETF定为标准RFC 6455，并由RFC7936补充规范。WebSocket API也被W3C定为标准。

WebSocket使得客户端和服务器之间的数据交换变得更加简单，允许服务端主动向客户端推送数据。在WebSocket API中，浏览器和服务器只需要完成一次握手，两者之间就直接可以创建持久性的连接，并进行双向数据传输。

为什么有了HTTP协议还要WebSocket

HTTP协议采用的是客户端（浏览器）轮询的方式，即客户端发送请求，服务端做出响应，为了获取最新的数据，需要不断的轮询发出HTTP请求，占用大量带宽。
WebSocket采用了一些特殊的报头，使得浏览器和服务器只需要通过“握手”建立一条连接通道后，此链接保持活跃状态，之后的客户端和服务器的通信都使用这个连接，解决了Web实时性的问题，相比于HTTP有一下好处：

一个Web客户端只建立一个TCP连接
WebSocket服务端可以主动推送（push）数据到Web客户端
有更加轻量级的头，减少了数据传输量

特点

建立在TCP协议只上，服务端比较容易实现
于HTTP协议有良好的兼容性，默认端口也是80和443，握手阶段使用HTTP协议，因此握手时不容易屏蔽，能通过各种HTTP代理服务器
数据格式轻量，通信高效且节省带宽
支持传输文本数据和二进制数据
没有同源限制，客户端可以与任意服务器通信
也支持加密传输，WS+SSL，URL形如wss://

技术

jdk8
maven
SpringBoot2.6.11
websocket
fastjosn

实现

pom.xml

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0" xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 https://maven.apache.org/xsd/maven-4.0.0.xsd">
    <modelVersion>4.0.0</modelVersion>
    <parent>
        <groupId>org.springframework.boot</groupId>
        <artifactId>spring-boot-starter-parent</artifactId>
        <version>2.6.11</version>
        <relativePath/> <!-- lookup parent from repository -->
    </parent>
    <groupId>com.websocket</groupId>
    <artifactId>springboot_websocket</artifactId>
    <version>0.0.1-SNAPSHOT</version>
    <name>springboot_websocket</name>
    <description>springboot_websocket</description>
    <properties>
        <java.version>1.8</java.version>
    </properties>
    <dependencies>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-web</artifactId>
        </dependency>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-websocket</artifactId>
        </dependency>
        <dependency>
            <groupId>com.alibaba</groupId>
            <artifactId>fastjson</artifactId>
            <version>1.2.3</version>
        </dependency>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-devtools</artifactId>
            <scope>runtime</scope>
            <optional>true</optional>
        </dependency>
        <dependency>
            <groupId>org.projectlombok</groupId>
            <artifactId>lombok</artifactId>
            <optional>true</optional>
        </dependency>
        <dependency>
            <groupId>org.springframework.boot</groupId>
            <artifactId>spring-boot-starter-test</artifactId>
            <scope>test</scope>
        </dependency>
    </dependencies>

    <build>
        <plugins>
            <plugin>
                <groupId>org.springframework.boot</groupId>
                <artifactId>spring-boot-maven-plugin</artifactId>
                <configuration>
                    <excludes>
                        <exclude>
                            <groupId>org.projectlombok</groupId>
                            <artifactId>lombok</artifactId>
                        </exclude>
                    </excludes>
                </configuration>
            </plugin>
        </plugins>
    </build>

</project>

websocket核心配置

package com.websocket.springboot_websocket.config;

import org.springframework.context.annotation.Bean;
import org.springframework.context.annotation.Configuration;
import org.springframework.web.socket.server.standard.ServerEndpointExporter;

/**
 * @Program: springboot_websocket
 * @ClassName WebSocketConfig
 * @Author: liutao
 * @Description: websocket配置类
 * @Create: 2022-08-19 18:42
 * @Version 1.0
 **/
@Configuration
public class WebSocketConfig {
    @Bean
    public ServerEndpointExporter serverEndpointExporter() {
        return new ServerEndpointExporter();
    }
}

配置websocket服务

package com.websocket.springboot_websocket.websocket;

import lombok.extern.slf4j.Slf4j;
import org.springframework.stereotype.Component;

import javax.websocket.*;
import javax.websocket.server.PathParam;
import javax.websocket.server.ServerEndpoint;
import java.util.ArrayList;
import java.util.Collections;
import java.util.List;
import java.util.concurrent.ConcurrentHashMap;
import java.util.concurrent.CopyOnWriteArraySet;

/**
 * @Program: springboot_websocket
 * @ClassName WebsocketServer
 * @Author: liutao
 * @Description: websocket服务
 * @Create: 2022-08-19 18:52
 * @Version 1.0
 **/
@Slf4j
@Component
@ServerEndpoint("/websocket/{userId}")
public class WebSocketServer {
//    在线人数
    private static int onlineCount;
//    当前会话
    private Session session;
//    用户唯一标识
    private String userId;

    private static CopyOnWriteArraySet<WebSocketServer> webSocketSet = new CopyOnWriteArraySet<>();

    /**
     * concurrent包的线程安全set，用来存放每个客户端对应的MyWebSocket对象
     */
    private static ConcurrentHashMap<String,WebSocketServer> webSocketMap = new ConcurrentHashMap();

    /**
     * 为了保存在线用户信息，在方法中新建一个list存储一下【实际项目依据复杂度，可以存储到数据库或者缓存】
     */
    private final static List<Session> SESSIONS = Collections.synchronizedList(new ArrayList<>());

 /**
  * @methodName: onOpen
  * @description: 建立连接
  * @Author LiuTao
  * @param  [session, userId]
  * @updateTime 2022/8/19 19:31
  * @return void
  * @throws
  **/
 @OnOpen
    public void onOpen(Session session, @PathParam("userId") String userId) {
        this.session = session;
        this.userId = userId;
        webSocketSet.add(this);
        SESSIONS.add(session);
        if (webSocketMap.containsKey(userId)) {
            webSocketMap.remove(userId);
            webSocketMap.put(userId,this);
        } else {
            webSocketMap.put(userId,this);
            addOnlineCount();
        }
        log.info("[连接ID:{}] 建立连接, 当前连接数:{}", this.userId, getOnlineCount());
    }

   /**
    * @methodName: onClose
    * @description: 断开连接
    * @Author LiuTao
    * @param  []
    * @updateTime 2022/8/19 19:31
    * @return void
    * @throws
    **/
   @OnClose
    public void onClose() {
        webSocketSet.remove(this);
        if (webSocketMap.containsKey(userId)) {
            webSocketMap.remove(userId);
            subOnlineCount();
        }
        log.info("[连接ID:{}] 断开连接, 当前连接数:{}", userId, getOnlineCount());
    }

    /**
     * @methodName: onError
     * @description: 发送错误
     * @Author LiuTao
     * @param  [session, error]
     * @updateTime 2022/8/19 19:32
     * @return void
     * @throws
     **/
    @OnError
    public void onError(Session session, Throwable error) {
        log.info("[连接ID:{}] 错误原因:{}", this.userId, error.getMessage());
        error.printStackTrace();
    }

   /**
    * @methodName: onMessage
    * @description: 收到消息
    * @Author LiuTao
    * @param  [message]
    * @updateTime 2022/8/19 19:32
    * @return void
    * @throws
    **/
   @OnMessage
    public void onMessage(String message) {
        log.info("[连接ID:{}] 收到消息:{}", this.userId, message);
    }

    /**
     * @methodName: sendMessage
     * @description: 发送消息
     * @Author LiuTao
     * @param  [message, userId]
     * @updateTime 2022/8/19 19:32
     * @return void
     * @throws
     **/
    public void sendMessage(String message,Long userId) {
        WebSocketServer webSocketServer = webSocketMap.get(String.valueOf(userId));
        if (webSocketServer!=null){
            log.info("【websocket消息】推送消息,[toUser]userId={},message={}", userId,message);
            try {
                webSocketServer.session.getBasicRemote().sendText(message);
            } catch (Exception e) {
                e.printStackTrace();
                log.error("[连接ID:{}] 发送消息失败, 消息:{}", this.userId, message, e);
            }
        }
    }

    /**
     * @methodName: sendMassMessage
     * @description: 群发消息
     * @Author LiuTao
     * @param  [message]
     * @updateTime 2022/8/19 19:33
     * @return void
     * @throws
     **/
    public void sendMassMessage(String message) {
        try {
            for (Session session : SESSIONS) {
                if (session.isOpen()) {
                    session.getBasicRemote().sendText(message);
                    log.info("[连接ID:{}] 发送消息:{}",session.getRequestParameterMap().get("userId"),message);
                }
            }
        } catch (Exception e) {
            e.printStackTrace();
        }
    }

    /**
     * 获取当前连接数
     * @return
     */
    public static synchronized int getOnlineCount() {
        return onlineCount;
    }

    /**
     * 当前连接数加一
     */
    public static synchronized void addOnlineCount() {
        WebSocketServer.onlineCount++;
    }

    /**
     * 当前连接数减一
     */
    public static synchronized void subOnlineCount() {
        WebSocketServer.onlineCount--;
    }

}

web接口

package com.websocket.springboot_websocket.web;


import com.alibaba.fastjson.JSONObject;
import com.websocket.springboot_websocket.websocket.WebSocketServer;
import lombok.Data;
import lombok.experimental.Accessors;
import org.springframework.beans.factory.annotation.Autowired;
import org.springframework.web.bind.annotation.GetMapping;
import org.springframework.web.bind.annotation.PathVariable;
import org.springframework.web.bind.annotation.RequestMapping;
import org.springframework.web.bind.annotation.RestController;

/**
 * @Program: springboot_websocket
 * @ClassName WebSocketController
 * @Author: liutao
 * @Description: websocket web层
 * @Create: 2022-08-19 19:01
 * @Version 1.0
 **/
@RestController
@RequestMapping("/ws")
public class WebSocketController {
    @Autowired
    private WebSocketServer webSocketServer;

    /**
     * 消息发送
     */
    @GetMapping("/send/{userId}/{msg}")
    public void send(@PathVariable String msg, @PathVariable String userId){
            webSocketServer.sendMessage(JSONObject.toJSONString(msg), Long.valueOf(String.valueOf(userId)));
    }

    /**
     * 群发消息测试(给当前连接用户发送)
     */
    @GetMapping("/sendMassMessage")
    public void sendMassMessage(){
        WebsocketResponse response = new WebsocketResponse();
        response.setTitle("群发主题");
        webSocketServer.sendMassMessage(JSONObject.toJSONString(response));
    }

    @Data
    @Accessors(chain = true)
    public static class WebsocketResponse {
        private String title;
        private String userId;
        private String userName;
        private int age;
    }

}
